Single phase meter
A single-phase meter is an electrical device used to measure energy consumption in single-phase power systems, typically in residential and small commercial settings. It records the amount of electricity consumed in kilowatt-hours (kWh) and ensures accurate billing. These meters operate with a single alternating current (AC) phase and are commonly used for loads up to 240V. They can be analog (electromechanical) or digital (smart meters with remote monitoring capabilities).
- Estimated Delivery : From 0 to 7 business days
- Free Shipping & Returns : On all orders over N500,000
- Description
- Shipping
- Reviews(0)
- Questions & Answers
- Vendor Info
- Location
- More Products
- Warranty Policy
- Product Enquiry
Description
Product details
This energy meter can measure electrical parameters such as energy, voltage, current and power, and auto loop display the readings. Its compact and easy to install, safe to use.
Features:
LCD display: equipped with a LCD screen displaying digital readings, which is easy to read.
Auto loop display four data: the readings of energy consumption, voltage, current and power will be automatically switched in the screen, each one stays for 6 seconds.
Quality material and high accuracy: retardant housing to ensure safety, SMT chip technology integrated circuit provides accurate measurement, excellent conductivity, corrosion resistance, and stable performance.
Compact and user-friendly: 35mm rail for installation, and can be directly installed in the electric box, occupying only 2P position.
Specifications:
Material: ABS
Model: DDSU1897
Display: LCD without Backlight
Wiring: top points for input and bottom points for output, or vice versa
Current: 5(60)A/5(80)A
Voltage: 220VAC/50Hz
Power: 17000W
Mounting: Distribution box / DIN rail
Display: LCD
Operating Temperature: -20℃~55℃
Item Size: 7.85 * 3.65 * 4.3cm / 3.09 * 1.43 * 1.69in
Item Weight: 100g / 3.52oz
Package Weight: 135g / 4.76oz
Package Size: 8 * 5 * 5cm / 3.14 * 1.96 * 1.96in
Packing List:
1 * Energy Meter
1 * User Manual
Specifications
Key Features
- LCD display: equipped with a LCD screen displaying digital readings, which is easy to read.
- Auto loop display four data: the readings of energy consumption, voltage, current and power will be automatically switched in the screen, each one stays for 6 seconds.
- Quality material and high accuracy: retardant housing to ensure safety, SMT chip technology integrated circuit provides accurate measurement, excellent conductivity, corrosion resistance, and stable performance.
- Compact and user-friendly: 35mm rail for installation, and can be directly installed in the electric box, occupying only 2P position.
Specifications
- SKU: GE779IP2C1DO0NAFAMZ
- Product Line: beibelacus@gmail.com
- Weight (kg): 0.14
- Color: nature
- Main Material: N/A
